Large Centrifugal Castings
From crushing hard rocks and minerals to lifting heavy loads, large industrial machinery is constantly pushed to the limit. Improve performance and longevity with centrifugally cast metal parts from U.S. Bronze Foundry & Machine
What’s centrifugal casting?
Large centrifugal castings create finished products by pouring molten metal into a spinning cylindrical mold. The mold is reusable, and metal is poured through an opening at the top of the spinning mold. Inside of it are chambers with the desired product shape or features.
The centrifugal force generated from the rotation exerts pressure onto the molten metal, causing it to conform to the mold’s shape. When the metal cools and solidifies, the mold halves are separated, and the finished part is removed.
The Centrifugal Casting Edge
Centrifugal casting produces metal parts with optimum accuracy and minimal waste. The process is perfect for manufacturing round castings with an inside diameter.
There are many advantages to using centrifugal casting for the manufacture of cylindrical and circular parts. They include:
- Faster turnaround
- Large Flange Offsets
- Higher Quality
- Better production throughput
- Lower cost production process
- Flexibility in casting size envelope
- Inhouse Engineering and Design
The extreme pressures placed upon the mold during rotation cause lighter contaminants and impurities to separate from the denser metal. These impurities gather in the component’s bore, minimizing chances that voids, or porosity will form within the crystalline metal structure. The machining process can easily remove these impurities. As a result, the final product is materially sound and free from defects. With casting capabilities ranging from 1” to 158” diameter, there is no job too big or too small.
Capabilities and Area Of Expertise
Our area of expertise is large centrifugal castings for heavy machinery. We are the premier foundry for producing components for oversized industrial equipment and infrastructure components. Here are our capabilities:
- Castings up to 35,000 pounds
- Lengths of up to 80 inches
- Outside diameters as large as 158 inches
We utilize multiple molding processes that allow us to meet your project requirements and select the optimal manufacturing path. Below are examples of products we regularly manufacture.
- Straight Bushings
- Trunnion Bearings
- Inserts
- Lift Pads
- Wear Plates
- Liners
- Screw Down Nut Blanks
- Gear Blanks And Gear Worm Blanks
- Rings
- Washers
- Thrust Collars
- Cylinders
- Shaft Sleeves
- Tapered Bushings
- Split Bushings
- Flange Bushings
- Eccentric Bushings
Critical parts, quality materials
Wear, corrosion, extreme temperatures, and other degrading factors are part and parcel of industrial processes. Premium materials should be used to manufacture vital components to avoid premature degradation from these environments.
As a leading centrifugal casting manufacturer, we make products from various alloys. Metals we pour into centrifugal casting molds are:
- Leaded Tin Bronze
- C83600
- C92400
- C93200
- C93600
- C93700
- C93800
- C93900
- C94100
- C94300
- Tin Bronze
- C90300
- C90500
- C90700
- C90800
- C90900
- C91000
- C91100
- C91300
- C91700
- C92200
- C92700
- Aluminum Bronze
- C95200
- C95300
- C95400
- C95500
- C95520
- C95800
- Manganese Bronze
- C86200
- C86300
- C86400
- C86500
- Nickel Silver Bronze
- C96400
- C97300
- C97400
- C97600
- Silicon Bronze
- C87300
- C87500
- C87600
- C87850
- Other Alloys Upon Request – Feel Free to Ask One of Our Experts
- Leaded Nickel Tin Bronze
- Nickel Silver Bronze
- Copper Alloys
- Stainless Steels
- Aluminum
- Nickel
Get quality parts, affordable and fast
US Bronze Foundry and Machine is the premier foundry in producing both cast and finish machined castings. Along with casting we also offer subtractive manufacturing services. US Bronze Foundry & Machine additionally offers a suite of secondary processes. Our value-added services include:
- Machining
- Heat Treatment
- Metallurgical Testing
- Non-Destructive Examination, or NDE
Our foundry houses a full-service machine shop, making it possible to deliver finished castings with precise dimensions. The shop contains advanced CNC equipment capable of machining workpieces with:
- Outside diameters of 150 inches
- Lengths of 80 inches
- Tolerances are +/- .001 inches
Heat treatment can improve material working life, like increasing surface hardness, temperature resistance, ductility, and strength. Metallurgical testing confirms the mechanical and chemical characteristics of materials.
Non-destructive examination checks for imperfections or cracks that can degrade final product performance. Surface and subsurface inspections are performed upon request.
Innovative Castings Provider
U.S. Bronze Foundry & Machine is a leading centrifugal casting manufacturer and provider of centrifugally cast custom metal components. With a century of experience, we deliver products with the highest quality. Here’s our range of custom centrifugal casting services.
- Research & Design
- Mold-Making
- Prototyping
- Full-Scale Casting
- Finished Machining
- Inspection
- Delivery
Contact us to learn more about our centrifugal casting capabilities.
Strict quality protocols ensure parts are manufactured to applicable industry standards or client requirements. Turnaround of rough parts is as quick as two weeks, while completion of finished pieces is as swift as eight weeks, depending on lead time and other factors.
Related Applications
Let’s get started on your custom centrifugally cast parts
U.S. Bronze Foundry & Machine makes high-quality components for companies with challenging industrial processes. We work with you to produce centrifugal castings tailored for your application. Industries served are:
